Tendu Slim Plus

machalum

Properties:

Frame Depth

98 mm. to 134 mm.

Frame Height

52 mm.

Sash Depth

40 mm.

Sash Height

86 mm.

Max. Glass thickness

Up to 27 mm.

Max. Sash Weight

Up to 250 kg.

Sealing Type

Perimetrical, with two rows of high-denisty brushes EPDM gaskets for tilt and slide.

Performance:

Air Permability

(Class 3) up to 600 pa.

Water tightness

(Class 6A) up to 250 pa.

Resistance to Wind load

(Class B3) up to 1200 pa.

  • Offers an integrated sliding door solution with facade systems adding an aesthetic value to the glass facades (optional).

  • Offers an extensive range of accessories, including integrated lift & slide accessories.

  • Obtains excellent technical performance and air permeability classifications, using a gasket instead of a pile weatherstrip (optional).

  • Used for doors and windows with heavy, large sash to obtain a wide view.

​

​
